EDM Wire Cutting Machine
During the use of the servo system, if the limit switch is damaged or has poor contact, it will cause the servo system to have abnormal limit. The solution is to replace the limit switch or rewire it in a timely manner.
- Product Introduction
Reasons and solutions for abnormal limit of servo system on edm wire cutting machine
▲ 1.Mechanical reasons
1. Mechanical structure limit switch is damaged or has poor contact of edm wire cutting machine
During the use of the servo system, if the limit switch is damaged or has poor contact, it will cause the servo system to have abnormal limit. The solution is to replace the limit switch or rewire it in a timely manner.
2. Arm foreign object jamming
If the servo system gets stuck by foreign objects during operation, it will cause abnormal limit. At this point, it is necessary to remove the obstruction and readjust the mechanical structure according to the specific situation.
3. The servo motor is severely worn out
When the servo motor is severely worn, it will affect the motion state of the entire mechanical structure and also cause abnormal limit. In this case, it is necessary to replace the motor with severe wear and tear.
▲ 2.Electrical reasons
1. The parameter settings of the servo motor and servo driver do not match
When using a servo system of edm wire cutting machine, if the set motor parameters do not meet the requirements of the servo drive, limit abnormalities may occur. At this point, it is necessary to carefully check and reset the parameters.
2. The parameter settings of the servo drive and servo controller do not match
If the parameter settings between the servo drive and servo controller do not match, it can also lead to the occurrence of limit abnormalities. At this point, it is necessary to reset the parameters and conduct testing.
3. Servo drive overcurrent or overvoltage protection
Overcurrent or overvoltage protection of servo drives can also cause limit abnormalities. In this case, it is necessary to identify the cause of overcurrent or overvoltage, such as excessive power load or voltage fluctuations, and provide targeted solutions.
In short, abnormal limit of servo system of edm wire cutting machine is a common problem. When dealing with such problems, it is necessary to carefully analyze the cause of the problem and solve it in a targeted manner. Only in this way can the normal operation of the servo system be ensured without affecting work efficiency.
