Heavy-Duty CNC Milling-Machine Center
Heavy-Duty CNC Milling-Machine center often encounters the problem of machining center colliding with machine when machining workpiece, which not only affects the machining efficiency, but also may damage the workpiece and even cause personal injury.
- Product Introduction
Reasons for collision of Heavy-Duty CNC Milling-Machine center
Heavy-Duty CNC Milling-Machine center often encounters the problem of machining center colliding with machine when machining workpiece, which not only affects the machining efficiency, but also may damage the workpiece and even cause personal injury. What are the causes for collision of CNC machining center?
■ First, tool compensation input error is a common cause of collision:
1. Input error in coordinate offset compensation 60
2. Input error of workpiece coordinate G54
3. Length G43 compensates for H input error or recall error
4. Incorrect input or recall of radius G41 compensation D
5. G40 or G49 or G80 input error
In addition, in the field of machine tool processing, tool collision is a big headache. It seems small that the equipment collides with the knife, but it is actually very harmful. As an automatic precision equipment with high speed and high precision, CNC machining center will affect the machining efficiency in case of collision, and the overall accuracy of the machining center will be reduced in case of serious impact, and even the entire tool library will be rejected. Therefore, in our daily processing, we must pay attention to the problem of tool collision. To understand the cause of blade collision and take precautions in advance is an effective way to reduce blade collision.
Machine tool collision is very harmful to the accuracy of the machine tool, and the impact on different types of machine tools is also different. Generally speaking, the impact on the machine tool with weak rigidity is relatively large, while the impact on the machine tool with strong rigidity is relatively small under the same impact force. If the machine tool is of cantilever structure and the main shaft of the machine tool is installed on a revolving shaft, the precision of the machine tool will be fatal in case of collision. Therefore, for high-precision CNC machining center, collision shall be eliminated. Collision can be completely prevented and avoided as long as the operator is careful and master certain anti-collision methods.
The Heavy-Duty CNC Milling-Machine Center is a high-precision, industrial-grade machine designed for demanding machining applications. Combining the versatility of a machining center with the power of a CNC Milling Machine, this system delivers exceptional performance in metal cutting, large-part fabrication, and complex component manufacturing. For heavy and oversized workpieces, the Center Gantry Machining Center configuration provides superior rigidity, stability, and workspace flexibility.
